Best Screwdriver for PS5 Disassembly (Torx T8 & T10)

PS5 disassembly for cleaning, fan replacement, or SSD upgrade is a legitimately common DIY task as PS5s age past their original thermal-paste lifespan. Sony designed the PS5 around Torx T8 and T10 screws — larger and more forgiving than a laptop, smaller and more delicate than a desktop PC. The right electric driver sits in the middle of that range. Here's how the Fanttik E2 Ultra (and alternate E1 MAX) fit PS5 work.

The Quick Answer

Yes — the Fanttik E2 Ultra is a practical electric screwdriver for PS5 disassembly. As a precision driver with multiple torque levels, it handles the Torx T8 and T10 screws PS5s use across the case and heatsink mounts. The E1 MAX is an excellent alternative with its 50-bit set including both Torx sizes and a wider torque range.

Why This Question Matters

The PS5's three main disassembly touchpoints — the side panels (plastic snap-fit, no screws), the fan mount (one T8 screw), and the SSD expansion bay (one Phillips #0 screw) — each want different torque levels. Over-torque the fan mount and you can crack the plastic heatsink housing; under-torque the side-panel seat on reassembly and you get rattle. An electric driver with proper torque control makes the full teardown safer and faster.

The Specs You Need to Know

Step-by-Step: PS5 Fan Cleaning

1. Unplug everything from the PS5. Place it horizontally on a clean, static-safe surface.
2. Remove the plastic side panel by lifting the corner and sliding. No screws required.
3. Use the T8 bit on the E2 Ultra / E1 MAX (high torque or manual mode) to remove the single fan-cover screw.
4. Disconnect the fan cable. It's a small 4-pin JST connector — use plastic spudger, not metal.
5. Lift the fan out. Dust it with compressed air — do not blow directly into the bearing (use short, angled bursts).
6. Reassemble in reverse. Use manual mode at low speed for the fan screw seating.
7. Reinstall the plastic side panel — it clicks into place.

What to Watch Out For

• Heatsink removal for thermal-paste replacement is a separate, harder task. The spring-loaded Torx T9 / T10 heatsink screws cannot come fully out — they ride on internal springs. Loosen them in a cross pattern to avoid warping the heatsink.
• PS5 Slim redesigned some internals compared to the original PS5. The fan screw type is the same (T8), but the side-panel mechanism changed. Check iFixit's PS5 Slim guide for the model-specific procedure.
• Don't disassemble a PS5 that's still under Sony's standard warranty unless you're certain about what you're doing. Fan cleaning is low-risk; heatsink work voids warranty and requires thermal paste.

FAQ

Q: What screwdriver bits does a PS5 use?
A: Primarily Torx T8 (fan cover, some internal brackets), Torx T9/T10 (heatsink spring screws), and Phillips #0 (SSD cover). Both the Fanttik E2 Ultra and E1 MAX cover all of these.

Q: Is the Fanttik E2 Ultra safe for PS5 internals?
A: Yes. The E2 Ultra is designed for precision electronics work and includes the torque range needed (low for SSD/fan screws, manual for heatsink work).

Q: Can I upgrade a PS5 SSD with the E1 MAX?
A: Yes. The SSD expansion bay uses a single Phillips #0 screw — well within the E1 MAX's bit coverage and low-torque mode.

Verdict

For PS5 disassembly — fan cleaning, SSD upgrades, heatsink work — the Fanttik E2 Ultra precision electric screwdriver is a strong match. If you already own a Fanttik E1 MAX for phone / laptop repair, its 50-bit set and wider torque range also cover PS5 work. Either tool saves the frustration of trying to torque-match a manual Torx driver to a console heatsink.
